Client Analytics API

Overview

Investment Cafe Portal can be configured to capture information, on how each user interacts with the data presented on the screen.

Where this feature has been enabled, the Client Analytics API will allow you to request and download that data for a given period.

Getting Started

The following diagram provides an overview of the series of calls needed to obtain captured Client Analytics data from Investment Cafe.

Each Call Step by Step

1. Start by calling POST /v1/clientanalytics/data setting a name and the start date and end date of the period you wish to view client activity over.

Example of API request body


    {
        "name": "client-analytics-report-1",
        "startDateTime" : "2022-12-01T00:00:00.000Z",
        "endDateTime" : "2022-12-01T23:59:59.999Z"
    }



If successful, the service will return a 202 status code along with an ID (indicating that the report generation has been accepted and will commence shortly).

Example of API response


    {
        "id": 1,
        "message": "Request started successfully."
    }



2. To check the current status of the report generation request, allow 10 to 15 seconds, then call GET /v1/clientanalytics/data/meta?id=X (where X is the id returned in step 1). The jobState in the response indicates the current progress. If marked as IN_PROGRESS, then allow another 30 secs before calling this service again to confirm the generation has completed.

Example of API response


    {
        "id": 1,
        "name": "client-analytics-report-1",
        "created": "2022-12-01T17:57:29.280Z",
        "lastModified": null,
        "createdBy": "U0073",
        "startTime": "2022-12-01T00:00:00.000Z",
        "endTime": "2022-12-01T23:59:59.999Z",
        "jobState": "DONE"
    }



3. Once the jobState is marked as DONE, call GET /v1/clientanalytics/data?id=X to download the final report.

The downloadable file will be presented using the supplied 'name' from step 1 (e.g "client-analytics-report-1").


In the event the jobState returns as FAILED, proceed to delete the request by calling DELETE /v1/clientanalytics/data?id=X and repeat steps 1 to 3.

Validation Rules & Notes

- Searchable Client Analytics data is only available for up to 8 days into the past.
- Only 1 analytics report can be generated for a particular start and end date range.
- The report 'name' field is optional and will be automatically generated where not supplied.
- In all cases the report 'name' must be unique.
